供应PXK50W薄型全系列开关电源

           50W单路AC-DC开关电源

输入  输入电压AC170~264V

                          DC240~373V

          频率:47~440Hz

          冲击电流:50A/AC220V

输出 线性调整<1%的输出电压

          纹波及嗓声<1%的输出电压(mPV-P)

         温度系数±0.2%

         维持时间20ms

保持功能  过流超过标称值的125%动作

                 短路保护自动恢复

                 过压保护  达到115%~135%的电压标称值动作

绝缘强度      输入~输出  AC2000V  1分钟

                      输入~FG   AC 2000V  1分钟

                      输出~FG   AC500V  1分钟

绝缘电阻   输入~输出≥100MΩ,直流500V

                   输入~FG ≥100MΩ,直流500V

                   输出~FG  ≥100MΩ,直流500V

环境     使用环境-10℃~50℃,20%~90%  RH(无凝露)

             存储环境-20℃~85℃,10%~95%  RH(无凝露)

电源型号                        输出电压/电流                      效率

PXK50-03                          3.3V/10A                               72%

PXK50-05                          5.0V/10A                               78%

PXK50-09                          9.0V/6.0A                              79%

PXK50-12                         12V/4.2A                                80%

PXK50-24                         24V/2.1A                                84%

PXK50-15                         15V/3.3A                                82%

PXK50-18                         18V/3.0A                                82%

PXK50-30                         30V/1.6A                                85%

PXK50-36                         36V/1.5A                                85%

PXK50-48                         48V/1.0A                                87%

       50W多路AC-DC开关电源

电源型号                              输出电压/电流                                   效率

PXK50-D1                 5V/(1~6A)       12V/(0.1~1.5A)                        75%

PXK50-D2                 5V/(1~6A)       15V/(0.1~1.5A)                        75%

PXK50-D3                 5V/(1~6A)       24V/(0.1~1.5A)                        78%

PXK50-D4                 12V/(1~3A)    12V/(0.1~1.5A)                         80%

PXK50-D5                 15V/(1~3A)     15V/(0.1~1.5A)                        80%

PXK50-A                   5V/(0.5~6A)    ±12V/1A                                 80%

PXK50-B                   5V/(0.5~6A)    ±15V/1A                                 80%

PXK50-C                   5V/(0.5~6A)     12V/1A   -5V/1A                     80%

PXK50-X1                  12V/(0.5~2.5A)   5V/(0.1~1.5A)  12V/1A        82%

PXK50-324                3.3V/6A               24V/(0.1~1.5A)                    75%

PXK50-3A                  3.3V/6A                ±12V/1A                             74%

外形尺寸:112×88×34mm
